MIL-W-16878 PTFE vs. UL and CSA

Common Comparisons of Wall Thicknesses, Voltages, and Temperatures

AVG. WALL ⁽³⁾
AWG.
VOLTS
TEMP.°C
CONDUCTORS ⁽¹⁾
MIL-W-16878/6-ET
MIL-W-16878/23-ET
UL 1371
UL 1538
CSA
.005
.005
.005
.005
Goes to .010 in the next category
30-20
30-20
30-20
30-20
250
250
N/S(2)
N/S(2)
200
260
105
105
SPC
NPC
SPC, NPC
SPC, NPC
MIL-W-16878/4-E
MIL-W-16878/25-E
UL 1213
UL 1371
CSA 150V
.010
.010
.008
.008
.010
30-10
30-10
30-16
18-16
30-16
600
600
N/S(2)
N/S(2)
150
200
260
105
105
150(4)
SPC
NPC
SPC, NPC
SPC, NPC
SPC, NPC
MIL-W-16878/5-EE
MIL-W-16878/27-EE
UL 1180
UL 1815
CSA 300V
.013
.013
.013
.013
.010
30-10
30-10
30-10
30-10
28-10
1000
1000
300
300
300
200
260
200
250
200/250(4)
SPC
NPC
SPC, NPC
NPC
SPC/NPC
No Equivalent Mil Spec for this wall thickness – See MIL-W-16878/EE
UL 1199
UL 1584
UL 1659
CSA 600V
CSA 1000V
.020
.022
.020
.012
.020
30-10
30-10
26-10
28-10
28-10
600
1000
600
600
1000
200
200
250
200/250(4)
200/250(4)
SPC, NPC
SPC
NPC
SPC/NPC
SPC/NPC

Notes

  1. Common conductors listed, others available such as “A” nickel, 27% NPC, and Alloys.
  2. NS = Not Specified.
  3. Wall tolerances outside of the average wall can still meet UL & CSA requirements based on actual minimum wall and actual conductor diameter.
  4. Please consult factory for verification on CSA 150°C, 200°C, and 250°C temperature ratings.
